IRAMS10UP60A
Dynamic Electrical Characteristics
VDD=VBS=VBIAS=15V, Io=1A, VD=9V, PWMIN=2kHz, VIN_ON=VIN_th+, VIN_OFF=VIN_th-
TA=25°C, unless otherwise specified
Symbol
TON
Definition
Min
Typ
470
615
300
750
9
Max
Units
ns
Input to output propagation turn-on delay time (see fig.11)
Input to output propagation turn-off delay time (see fig. 11)
Dead Time
-
-
-
-
-
-
-
-
-
-
TOFF
ns
DT
ns
I/TTrip
TFCLTRL
T/ITrip to six switch to turn-off propagation delay (see fig. 2)
Post ITrip to six switch to turn-off clear time (see fig. 2)
ns
ms
InternalNTC-ThermistorCharacteristics
Parameter
Typ
100 +/- 5%
2.522 + 17.3 % /- 14.9%
4250 +/- 3%
-40 / 125
Units
kΩ
Conditions
TC = 25°C
R25
Resistance
R125
B
Resistance
kΩ
TC = 125°C
R2 = R1e [B(1/T2 - 1/T1)]
B-Constant (25-50°C)
k
Temperature Range
°C
Typ. Dissipation constant
1
mW/°C
TC = 25°C
Note 1: For more details, see IR21365 data sheet
Note 2: Logic operational for Vs from V--5V to V-+600V. Logic stata held for VS from V--5V to V--VBS. (Please refer to
DT97-3 for more details)
Thermistor Built-in IRAMS10UP60A
VCC (22)
NTC
IR21365
12K
T/ITRIP (21)
4.3k
VSS (23)
Note 3: The Maximum recommended sense voltage at the T/ITRIP terminal under normal operating conditions is 3.3V.
