X9C102, X9C103, X9C104, X9C503
Absolute Maximum Ratings
Thermal Information
Voltage on CS, INC, U/D and VCC with Respect to VSS . -1V to +7V
Voltage on VH/RH and VL/RL Referenced to VSS. . . . . . . -8V to +8V
ΔV = |VH/RH - VL/RL|
Temperature Under Bias . . . . . . . . . . . . . . . . . . . . .-65°C to +135°C
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . .-65°C to +150°C
Pb-Free Reflow Profile. . . . . . . . . . . . . . . . . . . . . . . . .see link below
http://www.intersil.com/pbfree/Pb-FreeReflow.asp
X9C102 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4V
X9C103, X9C104, and X9C503 . . . . . . . . . . . . . . . . . . . . . . . .10V
W (10s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8.8mA
Power Rating
*Pb-free PDIPs can be used for through-hole wave solder
processing only. They are not intended for use in Reflow solder
processing applications.
I
X9C102 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16mW
X9C103 X0C104, and X9C503 . . . . . . . . . . . . . . . . . . . . . .10mW
Recommended Operating Conditions
Commercial Temperature Range. . . . . . . . . . . . . . . . . 0°C to +70°C
Industrial Temperature Range . . . . . . . . . . . . . . . . . .-40°C to +85°C
Supply Voltage Range (VCC) . . . . . . . . . . . . . . . . . . . . . . . 5V ±10%
CAUTION: Do not operate at or near the maximum ratings listed for extended periods of time. Exposure to such conditions may adversely impact product reliability and
result in failures not covered by warranty.
Electrical Specifications Over recommended operating conditions unless otherwise stated.
LIMITS
TYP
SYMBOL
PARAMETER
TEST CONDITIONS
MIN
(Note 6)
MAX
UNIT
POTENTIOMETER CHARACTERISTICS
RTOTAL
VVH/RH
VVL/RL
IW
End-to-End Resistance Variation
-20
-5
+20
+5
%
VH Terminal Voltage
VL Terminal Voltage
Wiper Current
V
-5
+5
V
mA
-4.4
4.4
100
RW
Wiper Resistance
Wiper Current = ±1mA
Ref 1kHz
40
-120
20
Ω
Resistor Noise (Note 7)
Charge Pump Noise (Note 7)
Resolution
dBV
@ 850kHz
mVRMS
%
1
Absolute Linearity (Note 3)
Relative Linearity (Note 4)
VW(n)(actual) - VW(n)(EXPECTED)
-1
+1
MI (Note 5)
V
W(n + 1)(ACTUAL) - [VW(n) + MI
]
-0.2
+0.2 MI (Note 5)
ppm/°C
R
TOTAL Temperature Coefficient
TOTAL Temperature Coefficient
X9C103, X9C503, X9C104
X9C102
±300 (Note 7)
±600 (Note 7)
±20
R
ppm/°C
Ratiometric Temperature Coefficient
Potentiometer Capacitances
ppm/°C
CH/CL/CW
(Note 7)
See “Circuit #3 SPICE Macro
Model” on page 5.
10/10/25
pF
DC OPERATING CHARACTERISTICS
ICC
VCC Active Current
CS = V , U/D = VIL or VIH and
IL
1
3
mA
µA
INC = 0.4V to 2.4V at Max tCYC
ISB
Standby Supply Current
CS = VCC - 0.3V, U/D and
INC = VSS or VCC - 0.3V
200
750
±10
ILI
CS, INC, U/D Input Leakage Current
CS, INC, U/D input HIGH Voltage
CS, INC, U/D input LOW Voltage
CS, INC, U/D Input Capacitance (Note 7)
VIN = VSS to VCC
µA
V
VIH
VIL
CIN
2
0.8
V
VCC = 5V, VIN = VSS, TA = +25°C,
f = 1MHz
10
pF
FN8222.3
July 20, 2009
4
