MOBILE PENTIUM PROCESSOR WITH MMX™ TECHNOLOGY
Table 17. Parameters Used in the Specification of the First Order Input Buffer Model
Parameter
Cin
Description
Minimum and Maximum value of the capacitance of the input buffer model
Minimum and Maximum value of the package inductance
Minimum and Maximum value of the package capacitance
Diode Series Resistance
Lp
Cp
Rs
D1, D2
Ideal Diodes
PP0061
Figure 11. First Order Output Buffer Model
Table 18. Parameters Used in the Specification of the First Order Output Buffer Model
Parameter
Description
dV/dt
Minimum and maximum value of the rate of change of the open circuit voltage source used in
the output buffer model
RO
CO
LP
Minimum and maximum value of the output impedance of the output buffer model
Minimum and Maximum value of the capacitance of the output buffer model
Minimum and Maximum value of the package inductance
CP
Minimum and Maximum value of the package capacitance
