Signal Definitions
Table 5-1.
Name
V
TT
VTT_OUT
VTTPWRGD
Signal Definitions (Sheet 8 of 8)
Type
P
O
I
Description
The FSB termination voltage input pins. Refer to
for further details.
The VTT_OUT signals are included in order to provide a local V
TT
for some signals that
require termination to V
TT
on the motherboard.
The processor requires this input to determine that the supply voltage for BSEL[2:0]
and VID[5:0] is stable and within specification.
Notes
Notes:
1.
For this pin on Dual-Core Intel Xeon Processor 5000 series, the maximum number of symmetric agents is one. Maximum
number of priority agents is zero.
2.
For this pin on Dual-Core Intel Xeon Processor 5000 series, the maximum number of symmetric agents is two. Maximum
number of priority agents is zero.
3.
For this pin on Dual-Core Intel Xeon Processor 5000 series, the maximum number of symmetric agents is two. Maximum
number of priority agents is one.
§
68
Dual-Core Intel® Xeon® Processor 5000 Series Datasheet
