Electrical Specifications
Table 4.
Symbol
Voltage and Current Specifications (Sheet 2 of 2)
Parameter
Min
Typ
Max
Unit
Notes
ICC Deep Sleep for Celeron M processor Ultra
Low Voltage 383, 373 & VCC3
4,9,11,
12
3.0
A
IDSLPULV
ICC Deep Sleep for Celeron M processor Ultra
Low Voltage 353 & 0.940 V
3.0
A
4,9
dICC/DT
ICCA
VCC power supply current slew rate
ICC for VCCA Supply
0.5
120
2.5
A/ns
mA
A
6, 7
ICCP
ICC for VCCP supply
NOTES:
1.
The typical values shown are the VID encoded voltages. Static and ripple tolerances (for minimum and
maximum voltages) are defined in the loadline tables i.e., Table 5 through Table 7.
The voltage specifications are assumed to be measured at a via on the motherboard’s opposite side of the
processor’s socket (or BGA) ball with a 100-MHz bandwidth oscilloscope, 1.5-pF maximum probe
capacitance, and 1-MΩ minimum impedance. The maximum length of ground wire on the probe should be
less than 5 mm. Ensure external noise from the system is not coupled in the scope probe.
Specified at VCC,STATIC (nominal) under maximum signal loading conditions.
Specified at the VID voltage.
2.
3.
4.
5.
The ICCDES(max) specification comprehends future processor HFM frequencies. Platforms should be
designed to this specification.
6.
Based on simulations and averaged over the duration of any change in current. Specified by design/
characterization at nominal VCC. Not 100% tested.
7.
8.
Measured at the bulk capacitors on the motherboard.
Adherence to loadline specification for the Celeron M processor is required to ensure reliable processor
operation.
9.
Intel processor numbers are not a measure of performance. Processor numbers differentiate features
within each processor family, not across different processor families. See www.intel.com/products/
processor_number for details.
10.
11.
The Celeron M processor will support VCCA supply voltage of either 1.8 V ±5% or 1.5 V ±5%. Either one of
these voltages can be used on the platform.
These are VID values. Individual processor VID values may be calibrated during manufacturing such that
two devices at the same speed may have different VID settings. Actual voltage supplied to the processor
should be as specified in the load lines in Figure 5 and Figure 6. Adherence to load line specifications is
required to ensure reliable processor operation.
12.
For 350J and 360J, CPU signature = 06D8h.
Datasheet
21
