Processor Configuration Registers
2.10.38 LCAP—Link Capabilities Register
This register indicates PCI Express* device-specific capabilities.
B/D/F/Type:
Address Offset:
Reset Value:
Access:
0/6/0/PCI
AC–AFh
0521CC42h
RO, RW-O, RO-V, RW-OV
32 bits
Size:
BIOS Optimal Default
0h
Reset
Value
RST/
PWR
Bit
Access
Description
Port Number (PN)
Indicates the PCI Express port number for the given PCI Express
link. Matches the value in Element Self Description[31:24].
The value if this field differs between root ports
2h = device 1 Function 0
3h = device 1 Function 1
4h = device 1 Function 2
5h = device 6 Function 0
31:24
23:22
RO
RO
05h
0h
Uncore
Reserved (RSVD)
Link Bandwidth Notification Capability (LBNC)
A value of 1b indicates support for the Link Bandwidth
Notification status and interrupt mechanisms. This capability is
required for all Root Ports and Switch downstream ports
supporting Links wider than x1 and/or multiple Link speeds.
This field is not applicable and is reserved for Endpoint devices,
PCI Express to PCI/PCI-X bridges, and Upstream Ports of
Switches.
21
RO
1b
Uncore
Devices that do not implement the Link Bandwidth Notification
capability must hardwire this bit to 0b.
Data Link Layer Link Active Reporting Capable (DLLLARC)
For a Downstream Port, this bit must be set to 1b if the
component supports the optional capability of reporting the
DL_Active state of the Data Link Control and Management State
Machine. For a hot-plug capable Downstream Port (as indicated
by the Hot-Plug Capable field of the Slot Capabilities register),
this bit must be set to 1b.
For Upstream Ports and components that do not support this
optional capability, this bit must be hardwired to 0b.
Note: PCI Express* Hot-Plug is not supported on the processor.
20
19
RO
RO
0b
0b
Uncore
Uncore
Surprise Down Error Reporting Capable (SDERC)
For a Downstream Port, this bit must be set to 1b if the
component supports the optional capability of detecting and
reporting a Surprise Down error condition.
For Upstream Ports and components that do not support this
optional capability, this bit must be hardwired to 0b.
Clock Power Management (CPM)
A value of 1b in this bit indicates that the component tolerates
the removal of any reference clock(s) when the link is in the L1
and L2/3 Ready link states. A value of 0b indicates the
component does not have this capability and that reference
clock(s) must not be removed in these link states.
This capability is applicable only in form factors that support
"clock request" (CLKREQ#) capability.
For a multi-function device, each function indicates its capability
independently. Power Management configuration software must
only permit reference clock removal if all functions of the
multifunction device indicate a 1b in this bit.
18
RO
RO
0b
0h
Uncore
17:15
Reserved (RSVD)
Datasheet, Volume 2
191
