Electrical Specifications
2.7.2
FSB Frequency Select Signals (BSEL[2:0])
The BSEL[2:0] signals are used to select the frequency of the processor input clock
(BCLK[1:0]). Table 18 defines the possible combinations of the signals and the
frequency associated with each combination. The required frequency is determined by
the processor, chipset, and clock synthesizer. All agents must operate at the same
frequency.
The Celeron D processor will operate at an 533 MHz FSB frequency (selected by a
133 MHz BCLK[1:0] frequency).
For more information about these signals, refer to Section 4.2.
Table 18.
BSEL[2:0] Frequency Table for BCLK[1:0]
BSEL2
BSEL1
BSEL0
FSB Frequency
L
L
L
L
L
H
H
L
RESERVED
133 MHz
L
H
H
H
H
L
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
L
H
H
H
H
L
H
H
L
L
2.7.3
Phase Lock Loop (PLL) and Filter
VCCA and VCCIOPLL are power sources required by the PLL clock generators for the
Celeron D processor silicon. Since these PLLs are analog in nature, they require low
noise power supplies for minimum jitter. Jitter is detrimental to the system: it degrades
external I/O timings as well as internal core timings (i.e., maximum frequency). To
prevent this degradation, these supplies must be low pass filtered from VTT.
The AC low-pass requirements, with input at VTT are as follows:
• < 0.2 dB gain in pass band
• < 0.5 dB attenuation in pass band < 1 Hz
• > 34 dB attenuation from 1 MHz to 66 MHz
• > 28 dB attenuation from 66 MHz to core frequency
