Pin Listing and Signal Definitions
Table 37. Signal Description (Page 2 of 8)
Name
Type
Description
BINIT# (Bus Initialization) may be observed and driven by all processor system bus
agents and if used, must connect the appropriate pins of all such agents. If the
BINIT# driver is enabled during power-on configuration, BINIT# is asserted to
signal any bus condition that prevents reliable future operation.
If BINIT# observation is enabled during power-on configuration, and BINIT# is
sampled asserted, symmetric agents reset their bus LOCK# activity and bus
request arbitration state machines. The bus agents do not reset their IOQ and
transaction tracking state machines upon observation of BINIT# activation. Once
the BINIT# assertion has been observed, the bus agents will re-arbitrate for the
system bus and attempt completion of their bus queue and IOQ entries.
Input/
Output
BINIT#
If BINIT# observation is disabled during power-on configuration, a central agent
may handle an assertion of BINIT# as appropriate to the error handling architecture
of the system.
BNR# (Block Next Request) is used to assert a bus stall by any bus agent who is
unable to accept new bus transactions. During a bus stall, the current bus owner
cannot issue any new transactions.
Input/
Output
BNR#
BPM[5:0]# (Breakpoint Monitor) are breakpoint and performance monitor signals.
They are outputs from the processor which indicate the status of breakpoints and
programmable counters used for monitoring processor performance. BPM[5:0]#
should connect the appropriate pins of all Mobile Intel Pentium 4 Processor-M
system bus agents.
BPM4# provides PRDY# (Probe Ready) functionality for the TAP port. PRDY# is a
processor output used by debug tools to determine processor debug readiness.
Input/
Output
BPM[5:0]#
BPM5# provides PREQ# (Probe Request) functionality for the TAP port. PREQ# is
used by debug tools to request debug operation of the processor.
Please refer to the Mobile Intel Pentium 4 Processor-M and Intel 845MP/
845MZ Chipset Platform Design Guide.
These signals do not have on-die termination and must be terminated on the
system board.
BPRI# (Bus Priority Request) is used to arbitrate for ownership of the processor
system bus. It must connect the appropriate pins of all processor system bus
agents. Observing BPRI# active (as asserted by the priority agent) causes all other
agents to stop issuing new requests, unless such requests are part of an ongoing
locked operation. The priority agent keeps BPRI# asserted until all of its requests
are completed, then releases the bus by deasserting BPRI#.
BPRI#
BR0#
Input
BR0# drives the BREQ0# signal in the system and is used by the processor to
request the bus. During power-on configuration this pin is sampled to determine the
agent ID = 0.
Input/
Output
This signal does not have on-die termination and must be terminated.
BSEL[1:0] (Bus Select) are used to select the processor input clock frequency.
Table 5 defines the possible combinations of the signals and the frequency
associated with each combination. The required frequency is determined by the
processor, chipset and clock synthesizer. All agents must operate at the same
frequency. The Mobile Intel Pentium 4 Processor-M operates at a 400 MHz system
bus frequency (100 MHz BCLK[1:0] frequency). For more information about these
pins, including termination recommendations refer to Section 2.9 and the
appropriate platform design guidelines.
BSEL[1:0]
COMP[1:0]
Output
COMP[1:0] must be terminated on the system board using precision resistors.
Analog Refer to the Mobile Intel Pentium 4 Processor-M and Intel 845MP/845MZ
Chipset Platform Design Guide for details on implementation.
82
Mobile Intel Pentium 4 Processor-M Datasheet
