IA186ES/IA188ES
Data Sheet
8-Bit/16-Bit Microcontrollers
November 15, 2011
Bits [15–0]—PMODE [31–16] PIO Mode 1 Bits → For each bit, if the value is 1, the pin
is configured as an input. If 0, an output. The values of these bits correspond to those in
the PIO data registers and PIO Mode registers.
5.1.30 T1CON (05eh) and T0CON (056h)
Timer0 and Timer1 Mode and CONtrol Registers. These registers control the operation of
Timer0 and Timer1, respectively. The value of the T0CON and T1CON registers is 0000h at
reset (see Table 51).
Table 51. Timer0 and Timer1 Mode and Control Registers
15
14
13
12 11 10
9
0
8
0
7
0
6
0
5
4
3
P
2
1
0
EN INHn INT RIU
0
0
MC RTG
EXT ALT CONT
Bit [15]—EN Enable Bit → The timer is enabled when the EN bit is 1. The timer count
is inhibited when the EN bit is 0. Setting this bit to 1 by writing to the T2CON register
requires that the INHn bit be set to 1 during the same write. This bit is write-only and
can only be written if the INHn bit (Bit [14]) is set to 1 in the same operation.
Bit [14]—INHn Inhibit Bit → Gates the setting of the enable (EN) bit. This bit must be
set to 1 in the same write operation that sets the enable (EN) bit. This bit always reads
as 0.
Bit [13]—INT Interrupt Bit → An interrupt request is generated when the Count register
reaches its maximum, MC = 1, by setting the INT bit to 1. In dual maxcount mode, an
interrupt request is generated when the count register reaches the value in maxcount A or
maxcount B. No interrupt requests are generated if this bit is set to 0. If an interrupt
request is generated and then the enable bit is cleared before said interrupt is serviced, the
interrupt request will remain.
Bit [12]—RIU Register in Use Bit → This bit is set to 1 when the maxcount register B is
used to compare to the timer count value. It is set to 0 when the maxcount compare A
register is used.
Bits [11–6]—Reserved. Set to 0.
Bit [5]—MC Maximum Count → When the timer reaches its maximum count, this bit is
set to 1 regardless of the interrupt enable bit. This bit is also set every time maxcount
compare register A or B is reached when in dual maxcount mode. This bit may be used
by software polling to monitor timer status rather than through interrupts, if desired.
Bit [4]—RTG Retrigger Bit.
®
