XMC4500
XMC4000 Family
Summary of Features
•
•
•
Tri-stated in input mode
Push/pull or open drain output mode
Boundary scan test support over JTAG interface
On-Chip Debug Support
•
•
Full support for debug features: 8 breakpoints, CoreSight, trace
Various interfaces: ARM-JTAG, SWD, single wire trace
1.1
Ordering Information
The ordering code for an Infineon microcontroller provides an exact reference to a
specific product. The code “XMC4<DDD>-<Z><PPP><T><FFFF>” identifies:
•
•
<DDD> the derivatives function set
<Z> the package variant
– E: LFBGA
– F: LQFP
– Q: VQFN
•
•
<PPP> package pin count
<T> the temperature range:
– F: -40°C to 85°C
– K: -40°C to 125°C
<FFFF> the Flash memory size.
•
For ordering codes for the XMC4500 please contact your sales representative or local
distributor.
This document describes several derivatives of the XMC4500 series, some descriptions
may not apply to a specific product.
For simplicity the term XMC4500 is used for all derivatives throughout this document.
