XMC4500
XMC4000 Family
Summary of Features
1.2
Device Types
These device types are available and can be ordered through Infineon’s direct and/or
distribution channels.
Table 1
Derivative1)
Synopsis of XMC4500 Device Types
Package
Flash
SRAM
Kbytes
Kbytes
XMC4500-E144F1024
XMC4500-F144x1024
XMC4500-F100x1024
XMC4500-F144x768
XMC4500-F100x768
XMC4502-F100x768
XMC4504-F144x512
XMC4504-F100x512
PG-LFBGA-144
PG-LQFP-144
PG-LQFP-100
PG-LQFP-144
PG-LQFP-100
PG-LQFP-100
PG-LQFP-144
PG-LQFP-100
1024
1024
1024
768
160
160
160
160
160
160
128
128
768
768
512
512
1) x is a placeholder for the supported temperature range.
1.3
Device Type Features
The following table lists the available features per device type.
Table 2
Features of XMC4500 Device Types
Derivative1)
LEDTS SDMMC EBU ETH USB USIC MultiCAN
Intf.
Intf.
Intf.2) Intf. Intf. Chan. Nod./Msg.
3)
XMC4500-E144F1024
XMC4500-F144x1024
XMC4500-F100x1024
XMC4500-F144x768
XMC4500-F100x768
XMC4502-F100x768
XMC4504-F144x512
XMC4504-F100x512
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
SDM MR
SDM MR
1
1
1
1
1
1
-
3 x 2 3 / 64
3 x 2 3 / 64
3 x 2 3 / 64
3 x 2 3 / 64
3 x 2 3 / 64
3 x 2 3 / 64
M16
R
SDM MR
M16
M16
SDM
M16
R
-
-
3 x 2
3 x 2
-
-
-
-
1) x is a placeholder for the supported temperature range.
2) Memory types supported S=SDRAM, D=DEMUX, M=MUX 16-bit and 32-bit, M16=MUX 16-bit
3) Supported interfaces, M=MII, R=RMII.
Data Sheet
11
V1.0, 2013-01
Subject to Agreement on the Use of Product Information
