XMC4500
XMC4000 Family
Summary of Features
Table 3
Derivative1)
Features of XMC4500 Device Types
ADC DSD DAC
Chan. Chan. Chan. Slice
CCU4
CCU8
Slice
POSIF
Intf.
XMC4500-E144F1024
XMC4500-F144x1024
XMC4500-F100x1024
XMC4500-F144x768
XMC4500-F100x768
XMC4502-F100x768
XMC4504-F144x512
XMC4504-F100x512
32
32
24
32
24
24
32
24
4
4
4
4
4
4
4
4
2
2
2
2
2
2
2
2
4 x 4
4 x 4
4 x 4
4 x 4
4 x 4
4 x 4
4 x 4
4 x 4
2 x 4
2 x 4
2 x 4
2 x 4
2 x 4
2 x 4
2 x 4
2 x 4
2
2
2
2
2
2
2
2
1) x is a placeholder for the supported temperature range.
1.4
Definition of Feature Variants
The XMC4500 types are offered with several memory sizes and number of available
VADC channels. Table 4 describes the location of the available Flash memory, Table 5
describes the location of the available SRAMs, Table 6 the available VADC channels.
Table 4
Flash Memory Ranges
Total Flash Size
Cached Range
Uncached Range
512 Kbytes
0800 0000H −
0C00 0000H −
0807 FFFFH
0C07 FFFFH
768 Kbytes
0800 0000H −
0C00 0000H −
080B FFFFH
0C0B FFFFH
1,024 Kbytes
0800 0000H −
0C00 0000H −
080F FFFFH
0C0F FFFFH
Table 5
SRAM Memory Ranges
Total SRAM Size Program SRAM
System Data SRAM Communication
Data SRAM
128 Kbytes
160 Kbytes
1000 0000H −
1000 FFFFH
2000 0000H −
2000 FFFFH
−
1000 0000H −
2000 0000H −
3000 0000H −
1000 FFFFH
2000 FFFFH
3000 7FFFH
Data Sheet
12
V1.0, 2013-01
Subject to Agreement on the Use of Product Information
