XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
Functional Description
MultiCAN Features
•
CAN functionality conforms to CAN specification V2.0 B active for each CAN node
(compliant to ISO 11898)
•
•
•
•
•
•
Up to five independent CAN nodes
128 independent message objects (shared by the CAN nodes)
Dedicated control registers for each CAN node
Data transfer rate up to 1 Mbit/s, individually programmable for each node
Flexible and powerful message transfer control and error handling capabilities
Full-CAN functionality for message objects:
– Can be assigned to one of the CAN nodes
– Configurable as transmit or receive objects, or as message buffer FIFO
– Handle 11-bit or 29-bit identifiers with programmable acceptance mask for filtering
– Remote Monitoring Mode, and frame counter for monitoring
Automatic Gateway Mode support
16 individually programmable interrupt nodes
Analyzer mode for CAN bus monitoring
•
•
•
Data Sheet
63
V0.91, 2007-02
Draft Version
