TLI4946
Functional Description
2.3
Pin Description
Table 1
PIN Definitions for the PG-SC59-3-4 package
PIN No.
Name
Vs
Q
Function
Supply Voltage
Output
1
2
3
GND
Ground
Table 2
PIN Definitions for the PG-SSO-3-2 package
PIN No.
Name
Vs
GND
Q
Function
Supply Voltage
Ground
1
2
3
Output
2.4
Block Diagram
VS
Voltage Regulator
reverse polarity protected
Bias and
Compensation
Circuits
Oscillator
and
Sequencer
Q
Ref
GND
Low
Pass
Filter
Comparator
with
Amplifier
Chopped
Hysteresis
Hall Probe
Figure 2
TLI4946xy Block Diagram
Datasheet
9
Rev. 1.0, 2009-05-04
