TLE9879QXA40
System Control Unit - Power Modules (SCU-PM)
WDT1 (System Watchdog)
LP_CLK; clock source for all PMU submodules and WDT1
•
ICU (Interrupt Control Unit)
•
•
•
PREWARN_SUP_NMI; supply prewarning NMI request
PREWARN_SUP_INT; supply prewarning interrupt
grouping of peripheral interrupts for external interupt nodes:
– grouping single peripheral interrupts for interrupt node INT<2> (Measurement Unit (MU))
– grouping single peripheral interrupts for interrupt node INT<3> (ADC1-VAREF)
– grouping single peripheral interrupts for interrupt node INT<10> (UART1-LIN Transceiver)
– grouping single peripheral interrupts for interrupt node INT<14> (Bridge Driver)
Data Sheet
31
Rev. 1.0, 2015-04-30
