OPTIREG™ SBC TLE9274QXV33
High-speed CAN transceiver
Table 13 Electrical characteristics (cont’d)
Tj = -40°C to +150°C; VS = 5.5 V to 28 V; VCAN = 4.75 V to 5.25 V; RL = 60 Ω; CAN Normal mode; all voltages with
respect to ground, positive current flowing into pin (unless otherwise specified)
Parameter
Symbol
Values
Typ.
50
Unit Note or
Test Condition
Number
Min.
Max.
Propagation delay
TXDCAN LOW to bus
dominant
td(L),T
–
–
ns
ns
ns
CAN Normal mode; P_8.3.30
CL = 100 pF;
RL = 60 Ω;
VCAN = 5 V
Propagation delay
TXDCAN HIGH to bus
recessive
td(H),T
–
–
50
–
–
CAN Normal mode; P_8.3.31
CL = 100 pF;
RL = 60 Ω;
V
CAN = 5 V
Propagation delay
bus dominant to RXDCAN
LOW
td(L),R
100
CAN Normal mode; P_8.3.32
CL = 100 pF;
RL = 60 Ω;
V
CAN = 5 V;
CRXDCAN = 15 pF
Propagation delay
bus recessive to RXDCAN
HIGH
td(H),R
–
100
–
–
ns
ns
CAN Normal mode; P_8.3.33
CL = 100 pF;
RL = 60 Ω;
V
CAN = 5 V;
CRXDCAN = 15 pF
Received recessive bit width tbit(RXD)
400
550
CAN Normal mode; P_8.3.39
CL = 100 pF;
RL = 60 Ω;
V
CAN = 5 V;
CRXD = 15 pF;
bit(TXD) = 500 ns;
t
Parameter definition
in according to
Figure 23.
Transmitted recessive bit
width
tbit(BUS)
435
–
530
ns
CAN Normal mode; P_8.3.40
CL = 100 pF;
RL = 60 Ω;
VCAN = 5 V;
C
RXD = 15 pF;
tbit(TXD) = 500 ns;
Parameter definition
in according to
Figure 23.
Datasheet
57
Rev.2.0
2022-05-06
