TLE9263QX
High Speed CAN Transceiver
Table 17
Electrical Characteristics (cont’d)
VS = 5.5 V to 28 V; Tj = -40 °C to +150 °C; 4.75 V < VCAN < 5.25 V; RL = 60ꢀ; CAN Normal Mode; all voltages with
respect to ground, positive current flowing into pin
(unless otherwise specified)
Parameter
Symbol
Values
Typ.
Unit Note /
Test Condition
Number
Min.
Max.
Propagation Delay
TXD-to-RXD LOW
(recessive to dominant)
td(L),TR
–
150
255
ns
2)CAN Normal
Mode
CL = 100 pF;
RL = 60 ꢀ;
P_10.3.30
VCAN = 5 V;
CRXD = 15 pF
Propagation Delay
TXD-to-RXD HIGH
(dominant to recessive)
td(H),TR
–
150
255
ns
2)CAN Normal
Mode
CL = 100 pF;
RL = 60 ꢀ;
P_10.3.31
VCAN = 5 V;
CRXD = 15 pF
Propagation Delay
TXD LOW to bus dominant
td(L),T
td(H),T
td(L),R
–
–
–
50
–
–
–
ns
ns
ns
CAN Normal
Mode
CL = 100pF;
RL = 60 ꢀ;
P_10.3.32
P_10.3.33
P_10.3.34
VCAN = 5 V;
Propagation Delay
TXD HIGH to bus recessive
50
CAN Normal
Mode
CL = 100 pF;
RL = 60 ꢀ;
VCAN = 5 V;
Propagation Delay
bus dominant to RXD LOW
100
CAN Normal
Mode
CL = 100pF;
RL = 60 ꢀ;
VCAN = 5 V;
CRXD = 15 pF
Propagation Delay
bus recessive to RXD HIGH
td(H),R
–
100
–
ns
ns
CAN Normal
Mode
CL = 100pF;
RL = 60 ꢀ
P_10.3.35
P_10.3.46
VCAN = 5 V;
CRXD = 15 pF
Recessive Bit Width on RXD tbit(RXD)
(CAN FD up to 2Mbps)
400
–
550
CAN Normal
Mode
CL = 100pF;
RL = 60 ꢀ;
V
CAN = 5 V;
RXD = 15 pF;
bit(TXD) = 500ns;
C
t
Refer to
Figure 31
Data Sheet
72
Rev. 1.1, 2014-09-26
