TLE9263QX
LIN Transceiver
11
LIN Transceiver
11.1
Block Description
VSHS
SPI Mode Control
VCC1
Driver
TxD Input
Temp.-
Protection
Current
RTxD
RBUS
Output
Stage
TXDLIN
Timeout
Limit
LIN
To SPI Diagnostic
Receiver
VCC1
Filter
VSHS
RXDLIN
Wake
Receiver
Figure 32 Block Diagram
11.1.1
LIN Specifications
The LIN network is standardized by international regulations. The device is compliant to the specification LIN 2.2.
The physical layer specification LIN 2.2 is a super set of the previous LIN specifications, like LIN 2.0 or LIN 1.3.
The integrated LIN transceivers are according to the LIN 2.2 standard.
The device is compliant to the physical layer standard SAE-J2602-2. The SAE-J2602-2 standard differs from the
LIN 2.2 standard mainly by the lower data rate (10.4 kbit/s).
Data Sheet
75
Rev. 1.1, 2014-09-26
