TLE9263QX
External Voltage Regulator 3
Table 14
Electrical Characteristics (cont’d)
Parameter
Symbol
Values
Unit Note / Test Condition
Number
Min.
4.8
Typ. Max.
External Regulator Output
Voltage
(VCC3 = 5.0V)
VCC3,out3
VCC3,out4
VCC3,out5
5
5.2
V
V
V
–
2)SBC Stop-, Sleep Mode; P_8.6.15
Stand-alone configuration
10µA < IVCC3 < IVCC3_peak,r
3)
External Regulator Output
Voltage
(VCC3 = 3.3V)
3.23
3.15
3.3V 3.37
3.3V 3.45
2)SBC Normal Mode;
P_8.6.22
stand-alone configuration
10 mA < IVCC3 < 300 mA;
2)SBC Stop-, Sleep Mode; P_8.6.23
External Regulator Output
Voltage
(VCC3 = 3.3V)
Stand-alone configuration
3)
10µA < IVCC3 < IVCC3_peak,r
Load Sharing Ratio
ICC1 : ICC3
RatioLS_1,VCC3 1 :
1.35
1 :
1 :
4)5)6.0V < VS < 28V;
SBC Normal Mode;
LS ratio for a 470 mꢀ
shunt resistor and total
load current of 300mA
4)5)6.0V < VS < 28V;
SBC Normal Mode;
LS ratio for a 1 ꢀ shunt
resistor and total load
current of 300mA
P_8.6.16
P_8.6.20
P_8.6.27
1.9
2.45
Load Sharing Ratio
ICC1 : ICC3
RatioLS_2,VCC3 1 :
0.67
1 :
1 :
–
–
0.95 1.23
Load Sharing Ratio
ICC1 : ICC3
RatioLS_3,VCC3 1 :
1.50
1 :
1 :
4)5) Tj = 150°C;
1.95 2.40
8.0V < VS < 18V;
SBC Normal Mode;
LS ratio for a 470 mꢀ
shunt resistor and total
load current of 300mA
Load Sharing Ratio
ICC1 : ICC3
RatioLS_4,VCC3 1 :
0.75
1 :
1 :
–
4)5) Tj = 150°C;
8.0V < VS < 18V;
P_8.6.28
0.98 1.21
SBC Normal Mode;
LS ratio for a 1 ꢀ shunt
resistor and total load
current of 300mA
1) Threshold at which the current limitation starts to operate. This threshold is only active when VCC3 is configured for stand-
alone configuration.
2) Tolerance includes load regulation and line regulation.
3) IVCC3_peak refers to the load current out of the collector of the external PNP device. This value can be calculated by
multiplying the VCC3base active peak threshold (IVCC3base,Ipeak) with the current gain of the PNP
4) Not subject to production test, specified by design.
5) a) Ratio will change depending on the chosen shunt resistor which value is correlating to the maximum power dissipation
of the PNP pass device. See Chapter 8.4 for the ratio calculation. The ratio will also change at low-drop operation.
For supply voltages of 5.5V < VS < 6V the accuracy applies only for a total load current of 250mA.
The load sharing ratio in SBC Stop Mode has +/-10% wider limits than specified.
b) The output voltage precision in load sharing in SBC Stop Mode is according to VCC1 +/-4% or better for loads up to
20mA and +/-2% with loads greater than 20mA.
In SBC Normal the +/-2% precision for 5V/3.3V tolerance is valid regardless of the applied load.
Data Sheet
55
Rev. 1.1, 2014-09-26
