TLE 6244X
Between -40°C and 150°C an
approximately linear characteristic
line can be assumed for the short
circuit shutdown threshold.
Between 17V ≤ UUBatt ≤ 21V, the
short circuit shutdown threshold is
switched.
A power stage that is switched off
in case of SCB can be switched on
again by an off/on cycle at the cor-
responding input pin resp. by the
change of the state of the corre-
sponding SPI bit SCONx (see
page 16), by the µsec-Bus, by a
DEL_DIA instruction or can be
released again by reset. If the fault
register is cleared before this
release (by a DEL_DIA instruc-
tion), a new fault entry of SCB is
immediately carried out, even if
SCB condition is no longer
present.
3.5.3.1 Maximum
Battery Volt-
age at Short
Circuit to Bat-
tery
See Note 1.11.1
C
B
U
1..6
36
60
V
OUT
3.5.4 Shutoff Delay Shutoff delay of the power stages
tVoff
215
µs
after detection of SCB
3.5.5 On Resis-
tance
OUT1,2,5,6: TJ = 25°C
OUT1,2,5,6: TJ = 150°C
OUT1,2,5,6: TJ = -40°C
OUT3,4: TJ = 25°C
A
A
A
A
A
A
Ron1,2,5,6
Ron1,2,5,6
Ron1,2,5,6
Ron3, 4
Ron3, 4
Ron3, 4
220
420
180
210
410
170
320
600
250
300
580
240
400
750
310
380
720
300
mΩ
mΩ
mΩ
mΩ
mΩ
mΩ
OUT3,4: TJ = 150°C
OUT3,4: TJ = -40°C
For UUBatt ≤ 10V Ron is increased
up to 20%.
3.5.6 On/off Delay
Times
„On“
B
B
B
C
C
tdon1...6
tson1...6
tdoff1...6
tsoff1...6
∆td
10
5
µs
µs
µs
µs
µs
„Off“
10
10
5
(Measurement with ohmic load)
|tdon - tdoff
|
switch-on slew rate
switch-off slew rate
C
C
son1...6
soff1...6
15
21
V/µs
V/µs
Final Data Sheet
47
V4.2, 2003-08-29
