TDA5235
Functional Description
x_WURSSIBH1. These two thresholds can be evaluated during normal operation of the
application to handle the actual interferer environment.
The blocking window can be disabled by setting x_WURSSIBH1 to the minimum value
and x_WURSSIBL1 to the maximum value.
wanted signal
x_WURSSIBH1
interferer
x_WURSSIBL1
wanted signal
x_WURSSITH1
noise floor
Figure 24
RSSI Blocking Thresholds
Threshold evaluation procedure
A statistical noise floor evaluation using read register RSSIPMF (RMS operation) leads
to the threshold x_WURSSITH1. The interferer thresholds x_WURSSIBL1 and
x_WURSSIBH1 are disabled when they are set to their default values.
For evaluation of the interferer thresholds, either use register RSSIPMF for RMS
operation or during SPM and WU (Wake-Up) on RSSI use register RSSIPWU to
statistically evaluate the interferer band. Finally the thresholds x_WURSSIBL1 and
x_WURSSIBH1 can be set.
Wake-Up on RSSI can also be applied as additional criterion when already using a
Wake-Up on Data criterion in Constant On-Off (COO) Mode.
Further details can be seen in Figure 10, Chapter 2.4.7 RSSI Peak Detector,
Chapter 2.6.2.2 Constant On-Off Time (COO) and Chapter 2.6.2.3 Fast Fall Back to
SLEEP (FFB).
NOTE: If e.g. an interferer ends/starts too close after/to the beginning/end of the
observation time, then a decision level error can arise. This is due to the filter dynamics
(settling time). Further, for interferer thresholds evaluation in SPM this changes interferer
statistics. Several interferer measurements are recommended to suppress this, what
makes sense anyway for a better distribution.
