TDA5235
Reference
#
Parameter
Symbol
Limit Values
Unit Test Conditions
Remarks
min. typ. max.
Digital Inputs/Outputs Characteristics
I1
I2
I3
High level input
voltage
VIn_High
IIn_High
VIn_Low
0.7*
VDDD
VDD5V V
+0.1
High level input
leakage current
5
µA
Low level input
voltage (except
P_ON pin)
0
0.8
V
I4
Low level input
voltage (at P_ON
pin)
VIn_Low_PON
0
0.5
V
I5
I6
Low level input
leakage current
IIn_Low
-5
µA
VDD5V
-0.4
High level output
voltage 1
VOut_High1
VDD5V V
IOH=-500 µA, static driver
capability;
Normal Pad Mode
(see register PPCFG2
and CMC0)
I7
I8
I9
Low level output
voltage 1
VOut_Low1
VOut_High2
VOut_Low2
0
0.4
V
IOL=500 µA, static driver
capability;
Normal Pad Mode
(see register PPCFG2
and CMC0)
VDD5V
-0.8
High level output
voltage 2
VDD5V V
IOH=-4 mA, static driver
capability;
High Power Pad Mode
(see register PPCFG2
and CMC0)
Low level output
voltage 2
0
0.8
V
IOL=4 mA, static driver
capability;
High Power Pad Mode
(see register PPCFG2
and CMC0)
Data Sheet
144
V1.0, 2010-02-19
