TDA 5210
preliminary
Reference
5.4 Bill of Materials
The following components are necessary for evaluation of the TDA5210 without
use of a Microchip HCS512 decoder.
Table 5-5 Bill of Materials
Ref
Value
100kΩ
100kΩ
820kΩ
240kΩ
360kΩ
10kΩ
Specification
0805, ± 5%
0805, ± 5%
0805, ± 5%
0805, ± 5%
0805, ± 5%
0805, ± 5%
R1
R2
R3
R4
R5
R6
L1
434 MHz: 15nH
869 MHz: 3.3nH
Toko, PTL2012-F15N0G
Toko, PTL2012-F3N3C
L2
434 MHz: 8.2pF
869 MHz: 3.9nH
0805, COG, ± 0.1pF
Toko, PTL2012-F3N9C
C1
C2
1pF
0805, COG, ± 0.1pF
434 MHz: 4.7pF
869 MHz: 3.9pF
0805, COG, ± 0.1pF
0805, COG, ± 0.1pF
C3
434 MHz: 6.8pF
869 MHz: 5.6pF
0805, COG, ± 0.1pF
0805, COG, ± 0.1pF
C4
C5
C6
100pF
47nF
0805, COG, ± 5%
1206, X7R, ± 10%
434 MHz: 10nH
869 MHz: 3.9pF
Toko, PTL2012-F10N0G
0805, COG, ± 0.1pF
C7
C8
100pF
0805, COG, ± 5%
434 MHz: 33pF
869 MHz: 22pF
0805, COG, ± 5%
0805, COG, ± 5%
C9
100pF
10nF
10nF
220pF
47nF
470pF
47nF
8.2pF
22pF
22nF
0805, COG, ± 5%
0805, X7R, ± 10%
0805, X7R, ± 10%
0805, COG, ± 5%
0805, X7R, ± 10%
0805, COG, ± 5%
0805, X7R, ± 5%
0805, COG, ± 0.1pF
0805, COG, ± 1%
0805, X7R, ± 5%
C10
C11
C12
C13
C14
C15
C16
C17
C18
Q1
(f – 10.7MHz)/32 or
HC49/U, fundamental mode, CL = 12pF,
e.g. 434.2MHz: Jauch Q 13,23437-S11-1323-12-10/20
e.g. 868.4MHz: Jauch Q 13,40155-S11-1323-12-10/20
RF
(f – 10.7MHz)/64
RF
Wireless Components
5 - 15
Specification, May 2001
