TDA 5210
preliminary
Reference
5.2 Test Circuit
The device performance parameters marked with ꢀ in Section 5.1.3 were mea-
sured on an Infineon evaluation board. This evaluation board can be obtained
together with evaluation boards of the accompanying transmitter device
TDA5100 in an evaluation kit that may be ordered on the INFINEON RKE
Webpage www.infineon.com/rke. In case a matching codeword is received,
decoded and accepted by the decoder the on-board LED will turn on. This sig-
nal is also accessible on a 2-pole pin connector and can be used for simple
remote-control applications. More information on the kit is available on request.
TDA5210_testboard_20_schematic.WMF
Figure 5-1
Schematic of the Evaluation Board
Wireless Components
5 - 12
Specification, May 2001
