TDA 5210
preliminary
Reference
5.1 Electrical Data
5.1.1 Absolute Maximum Ratings
WARNING
The maximum ratings may not be exceeded under any circumstances, not even
momentarily and individually, as permanent damage to the IC will result.
Table 5-1 Absolute Maximum Ratings, Ambient temperature T
=-40°C ... + 105°C
AMB
#
Parameter
Symbol
Limit Values
Unit
Remarks
min
-0.3
max
5.5
1
2
3
4
5
Supply Voltage
Vs
Tj
V
°C
Junction Temperature
Storage Temperature
Thermal Resistance
-40
-40
+150
+125
114
Ts
°C
RthJA
VESD
K/W
ESD integrity, all pins excl. Pins 1,3, 6, 28
ESD integrity Pins 1,3,6,28
+2
+1.5
kV
kV
HBM
according to
MIL STD
883D,
method
3015.7
Wireless Components
5 - 2
Specification, May 2001
