TC1796
General Device Information
Table 2
Symbol Pins I/O Pad
Class Supply
I/O A1
Pin Definitions and Functions (cont’d)
Power Functions
P3
VDDP
Port 3
Port 3 is a 16-bit bi-directional general-
purpose I/O port which can be alternatively
used for GPTA I/O lines.
P3.0
B12
A12
C13
B11
C12
A11
B10
C9
D10
C11
C10
D13
D11
D12
A10
B9
IN8 / OUT8 line of GPTA
IN9 / OUT9 line of GPTA
IN10 / OUT10 line of GPTA
IN11 / OUT11 line of GPTA
IN12 / OUT12 line of GPTA
IN13 / OUT13 line of GPTA
IN14 / OUT14 line of GPTA
IN15 / OUT15 line of GPTA
IN16 / OUT16 line of GPTA
IN17 / OUT17 line of GPTA
IN18 / OUT18 line of GPTA
IN19 / OUT19 line of GPTA
IN20 / OUT20 line of GPTA
IN21 / OUT21 line of GPTA
IN22 / OUT22 line of GPTA
IN23 / OUT23 line of GPTA
P3.1
P3.2
P3.3
P3.4
P3.5
P3.6
P3.7
P3.9
P3.8
P3.10
P3.11
P3.12
P3.13
P3.14
P3.15.
Data Sheet
20
V1.0, 2008-04
