型号：	SAK-TC399XP-256F300S BC
PDF下载：	下载PDF文件查看货源
内容描述：	[Infineon releases its second generation AURIX microcontroller in embedded flash 40 nm technology. It comes back with an increase in performance, memory sizes, connectivity and more scalability to address the new automotive trends and challenges. This family has more than 20 products to provide the most scalable portfolio of safety microcontroller. In terms of performance, the highest end product TC39x offers 6 cores running at 300 MHz and up to 6.9 MBytes embedded RAM, and consuming below 2 W. ]
分类和应用：
文件页数/大小：	548 页 / 21256 K
品牌：	INFINEON [ Infineon ]

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第5页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第6页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第7页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第8页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第10页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第11页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第12页

浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第13页

TC39x BC/BD-Step

Summary of Features

Ordering Information

The ordering code for Infineon microcontrollers provides an exact reference to the required product. This ordering

code identifies:

•

The derivative itself, i.e. its function set, the temperature range, and the supply voltage

The package and the type of delivery.

Table 1-1 Platform Feature Overview

Feature

TC39x

CPUs

Type

TC1.6.2

Cores / Checker Cores

6 / 4

Max. Freq.

300 MHz

Cache per CPU

SRAM per CPU

Program

32 KB

Data

16 KB

PSPR

64 KB

DSPR

240 KB for CPU0,1/ 96 KB else

DLMU

64 KB

SRAM global

LMU

768 KB

DAM

128 KB

Extension Memory

TCM

2 MB

XCM

16 KB

XTM

Program Flash

Size

16 MB

Banks

5 x 3 MB, 1 x 1 MB

Data Flash

DMA

Size (single-ended)

Channels

1 MB (DF0) + 128 KB (DF1)

128

CONVCTRL

EVADC

Modules

Primary Groups/Channels

Secondary Groups/Channels

Fast Compare Channels

Channels

8 / 64

4 / 64

EDSADC

Data Sheet

V 1.2, 2021-03

OPEN MARKET VERSION
