TC39x BC/BD-Step
Summary of Features
–
One Generic Timer Module (GTM) providing a powerful set of digital signal filtering and timer functionality
to realize autonomous and complex Input/Output management
–
–
–
–
–
–
–
One Capture / Compare 6 module (Two kernels CCU60 and CCU61)
One General Purpose 12 Timer Unit (GPT120)
4 channel Peripheral Sensor Interface conforming to V1.3 (PSI5)
1 Peripheral Sensor Interface with Serial PHY (PSI5-S)
2 Inter-Integrated Circuit Bus Interface (I2C) conforming to V2.1
1 IEEE802.3 Ethernet MAC with RMII and MII interfaces (ETH)
1 external Bus interface (EBU)
•
•
Versatile Successive Approximation ADC (VADC)
–
–
Cluster of 20 independent ADC kernels
Input voltage range from 0 V to 5.5V (ADC supply)
Delta-Sigma ADC (DSADC)
14 channels
–
•
•
•
•
•
•
•
•
Digital programmable I/O ports
On-chip debug support for OCDS Level 1 (CPUs, DMA, On Chip Buses)
multi-core debugging, real time tracing, and calibration
four/five wire JTAG (IEEE 1149.1) or DAP (Device Access Port) interface
Power Management System and on-chip regulators
Clock Generation Unit with System PLL and Peripheral PLL
Embedded Voltage Regulator
Qualified for automotive application according to AEC-Q100 (only applicable after delivery release of the
corresponding sales codes)
•
ISO 26262 Safety Element out of Context for safety requirements up to ASIL D (only applicable for sales codes
listed within a released Safety Package Release Note from IFX)
