TC39x BC/BD-Step
Electrical Specification5 V / 3.3 V switchable Pads
Table 3-14 Class S 3.3V (cont’d)
Parameter
Symbol
Values
Typ.
Unit
Note / Test Condition
Min.
Max.
Input low voltage level
VIL SR
-
-
0.42 *
V
AL
VDDM
-
-
-
-
0.8
0.5
V
V
TTL
TTL (degraded, used
for CIF)
Input low threshold variation
Pin capacitance
V
ILD SR
CIO CC
SET CC
-33
-
33
3
mV
pF
ns
max. variation of 1ms;
VDDM = constant; AL
-
-
2
-
in addition 2.5pF from
package to be added
Pad set-up time to get an
software update of the
configuration active
t
100
1) Hysteresis is implemented to avoid metastable states and switching due to internal ground bounce. It can't be guaranteed that
it suppresses switching due to external system noise.
2) Values for Pull-up resistor is defined via parameter RMDU in table VADC 5V.
3) Values for Pull-down resistor is defined via parameter RMDD in table VADC 5V.
Table 3-15 Class D
Parameter
Symbol
Values
Typ.
Unit
Note / Test Condition
Min.
Max.
150
300 1)
Input leakage current
I
OZ CC
-150
-300 1)
-
-
nA
nA
TJ ≤ 150°C; else
TJ ≤ 150°C; PDD option
available, or AltRef
option available and
EDSADC channel
connected, or two
EDSADC channels
connected
-300
-600 2)
-
-
300
600 2)
nA
nA
TJ ≤ 170°C; else
TJ ≤ 170°C; PDD option
available, or AltRef
option available and
EDSADC channel
connected, or two
EDSADC channels
connected
Pin capacitance
CIO CC
-
2
3
pF
in addition 2.5pF from
package to be added
1) For AN11 100 nA need to be added.
2) For AN11 200 nA need to be added.
Data Sheet
429
V 1.2, 2021-03
OPEN MARKET VERSION
