TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-2 Port 01 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
M2
P01.10
I
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 5 of TIM module 5
Mux input channel 2 of TIM module 5
Mux input channel 5 of TIM module 4
Trigger/Gate input, channel 9
Receive input channel 18
CDTM4_DTM0
GTM_TIM5_IN5_2
GTM_TIM5_IN2_9
GTM_TIM4_IN5_3
EDSADC_ITR9F
SENT_SENT18B
GTM_DTMT4_0
GTM_DTMA6_1
GTM_DTMT3_2
P01.10
CDTM6_DTM4
CDTM3_DTM0
O0
O1
O2
O3
O4
O5
O6
O7
I
General-purpose output
GTM muxed output
GTM_TOUT163
ASCLIN7_ASCLK
—
Shift clock output
Reserved
—
Reserved
—
Reserved
—
Reserved
EVADC_FC6BFLOUT
P01.11
Boundary flag output, FC channel 6
General-purpose input
Mux input channel 7 of TIM module 5
Mux input channel 3 of TIM module 5
Mux input channel 7 of TIM module 4
Trigger/Gate input, channel 9
Receive input channel 19
CDTM4_DTM0
M1
SLOW /
PU1 /
VEXT /
ES
GTM_TIM5_IN7_3
GTM_TIM5_IN3_11
GTM_TIM4_IN7_2
EDSADC_ITR9E
SENT_SENT19B
GTM_DTMT4_1
GTM_DTMA5_1
GTM_DTMA6_2
P01.11
CDTM5_DTM4
CDTM6_DTM4
O0
O1
O2
O3
O4
O5
O6
O7
General-purpose output
GTM muxed output
GTM_TOUT165
ASCLIN7_ASLSO
—
Slave select signal output
Reserved
—
Reserved
—
Reserved
—
Reserved
EVADC_FC7BFLOUT
Boundary flag output, FC channel 7
