TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-2 Port 01 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
L1
P01.8
I
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 4 of TIM module 5
Mux input channel 0 of TIM module 5
Mux input channel 4 of TIM module 4
CAN receive input node 0
Receive Channel B1
GTM_TIM5_IN4_2
GTM_TIM5_IN0_10
GTM_TIM4_IN4_2
CAN00_RXDF
ERAY1_RXDB1
EDSADC_DSDIN9A
SENT_SENT17B
ASCLIN0_ARXC
CAN20_RXDE
ASCLIN7_ARXB
P01.8
Digital datastream input, channel 9
Receive input channel 17
Receive input
CAN receive input node 0
Receive input
O0
O1
O2
O3
O4
O5
O6
O7
I
General-purpose output
GTM muxed output
GTM_TOUT162
—
Reserved
—
Reserved
—
Reserved
—
Reserved
—
Reserved
EVADC_FC4BFLOUT
P01.9
Boundary flag output, FC channel 4
General-purpose input
Mux input channel 2 of TIM module 5
Mux input channel 1 of TIM module 5
Mux input channel 2 of TIM module 4
Modulator clock input, channel 9
Receive input channel 16
General-purpose output
GTM muxed output
L2
SLOW /
PU1 /
VEXT /
ES
GTM_TIM5_IN2_1
GTM_TIM5_IN1_11
GTM_TIM4_IN2_1
EDSADC_DSCIN9A
SENT_SENT16B
P01.9
O0
O1
O2
O3
O4
O5
O6
O7
GTM_TOUT160
ASCLIN7_ATX
—
Transmit output
Reserved
—
Reserved
—
Reserved
EDSADC_DSCOUT9
EVADC_FC5BFLOUT
Modulator clock output
Boundary flag output, FC channel 5
