TC1767
Pinning
Table 4
Pin Definitions and Functions (PG-LQFP-176-5 Package1)) (cont’d)
Ctrl. Type Function
- - Digital Core Power Supply (1.5V)
Pin Symbol
10, VDD
213),
68,
84,
89,
99,
123,
153,
170
11, VDDP
20,
-
-
Port Power Supply (3.3V)
69,
83,
91,
100,
124,
139,
154,
171
12, VSS
22,
-
-
Digital Ground
70,
82,
85,
92,
101,
125,
140,
155,
172
105 VDDOSC
106 VDDOSC3
104 VSSOSC
141 VDDFL3
102 XTAL1
103 XTAL2
-
-
-
-
-
Main Oscillator and PLL Power Supply (1.5V)
Main Oscillator Power Supply (3.3V)
Main Oscillator and PLL Ground
Power Supply for Flash (3.3V)
Main Oscillator Input
-
-
-
I
O
Main Oscillator Output
Data Sheet
73
V1.3, 2009-09
