TC1767
Pinning
Table 4
Pin Definitions and Functions (PG-LQFP-176-5 Package1)) (cont’d)
Ctrl. Type Function
Pin Symbol
7
P5.6
I/O0 A1/
Port 5 General Purpose I/O Line 6
PU
IN46
I
GPTA0 Input 46
IN31
I
LTCA2 Input 31
OUT46
OUT14
Reserved
P5.7
O1
GPTA0 Output 46
O2
LTCA2 Output 14
O3
-
8
I/O0 A1/
Port 5 General Purpose I/O Line 7
PU
IN47
I
GPTA0 Input 47
OUT47
OUT15
Reserved
P5.8
O1
GPTA0 Output 47
O2
LTCA2 Output 15
O3
-
13
14
I/O0 A2/
Port 5 General Purpose I/O Line 8
PU
RDATA0B
Reserved
Reserved
OUT89
P5.9
I
MLI0 Receiver Data Input B
O1
-
O2
-
O3
LTCA2 Output 89
I/O0 A2/
Port 5 General Purpose I/O Line 9
PU
RVALID0B
Reserved
Reserved
OUT90
P5.10
I
MLI0 Receiver Data Valid Input B
O1
-
O2
-
O3
LTCA2 Output 90
15
16
I/O0 A2/
Port 5 General Purpose I/O Line 10
PU
RREADY0B
Reserved
OUT91
P5.11
O1
MLI0 Receiver Ready Input B
O2
-
O3
LTCA2 Output 91
I/O0 A2/
Port 5 General Purpose I/O Line 11
PU
RCLK0B
Reserved
Reserved
OUT92
I
MLI0 Receiver Clock Input B
O1
O2
O3
-
-
LTCA2 Output 92
Data Sheet
69
V1.3, 2009-09
