TC1767
Pinning
Table 4
Pin Symbol
169 P0.13
IN13
Pin Definitions and Functions (PG-LQFP-176-5 Package1)) (cont’d)
Ctrl. Type Function
I/O0 A1/
Port 0 General Purpose I/O Line 13
PU
I
GPTA0 Input 13
OUT13
OUT69
OUT13
175 P0.14
IN14
O1
GPTA0 Output 13
O2
GPTA0 Output 69
O3
LTCA2 Output 13
I/O0 A1/
Port 0 General Purpose I/O Line 14
GPTA0 Input 14
PU
I
REQ4
I
External Request Input 4
GPTA0 Output 14
OUT14
OUT70
OUT14
176 P0.15
IN15
O1
O2
GPTA0 Output 70
O3
LTCA2 Output 14
I/O0 A1/
Port 0 General Purpose I/O Line 15
GPTA0 Input 15
PU
I
REQ5
I
External Request Input 5
GPTA0 Output 15
OUT15
OUT71
OUT15
Port 1
O1
O2
O3
GPTA0 Output 71
LTCA2 Output 15
116 P1.0
IN16
I/O0 A2/
Port 1 General Purpose I/O Line 0
GPTA0 Input 16
PU
I
BRKIN
I
Break Input
OUT16
OUT72
OUT16
BRKOUT
119 P1.1
IN17
O1
GPTA0 Output 16
O2
GPTA0 Output 72
O3
LTCA2 Output 16
O
Break Output (controlled by OCDS module)
Port 1 General Purpose I/O Line 1
GPTA0 Input 17
I/O0 A1/
PU
I
OUT17
OUT73
OUT17
O1
O2
O3
GPTA0 Output 17
GPTA0 Output 73
LTCA2 Output 17
Data Sheet
57
V1.3, 2009-09
