C167CR
C167SR
Table 2
Pin Definitions and Functions
Input Function
Symbol Pin
Num. Outp.
P6
IO
Port 6 is an 8-bit bidirectional I/O port. It is bit-wise
programmable for input or output via direction bits. For a pin
configured as input, the output driver is put into high-
impedance state. Port 6 outputs can be configured as push/
pull or open drain drivers.
The Port 6 pins also serve for alternate functions:
P6.0
P6.1
P6.2
P6.3
P6.4
P6.5
P6.6
1
2
3
4
5
6
7
O
O
O
O
O
I
CS0
CS1
CS2
CS3
CS4
HOLD
HLDA
Chip Select 0 Output
Chip Select 1 Output
Chip Select 2 Output
Chip Select 3 Output
Chip Select 4 Output
External Master Hold Request Input
Hold Acknowledge Output (master mode)
or Input (slave mode)
I/O
P6.7
8
O
BREQ
Bus Request Output
P8
IO
Port 8 is an 8-bit bidirectional I/O port. It is bit-wise
programmable for input or output via direction bits. For a pin
configured as input, the output driver is put into high-
impedance state. Port 8 outputs can be configured as push/
pull or open drain drivers. The input threshold of Port 8 is
selectable (TTL or special).
The following Port 8 pins also serve for alternate functions:
P8.0
P8.1
P8.2
P8.3
P8.4
P8.5
P8.6
P8.7
9
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
CC16IO
CC17IO
CC18IO
CC19IO
CC20IO
CC21IO
CC22IO
CC23IO
CAPCOM2: CC16 Capture Inp./Compare Outp.
CAPCOM2: CC17 Capture Inp./Compare Outp.
CAPCOM2: CC18 Capture Inp./Compare Outp.
CAPCOM2: CC19 Capture Inp./Compare Outp.
CAPCOM2: CC20 Capture Inp./Compare Outp.
CAPCOM2: CC21 Capture Inp./Compare Outp.
CAPCOM2: CC22 Capture Inp./Compare Outp.
CAPCOM2: CC23 Capture Inp./Compare Outp.
10
11
12
13
14
15
16
