C167CR
Pin Definitions and Functions
Symbol Pin
Input (I)
Function
Number Output (O)
P6.0 -
P6.7
1 -
8
I/O
Port 6 is an 8-bit bidirectional I/O port. It is bit-wise
programmable for input or output via direction bits. For a pin
configured as input, the output driver is put into high-
impedance state. Port 6 outputs can be configured as push/
pull or open drain drivers.
The following Port 6 pins also serve for alternate functions:
1
...
5
6
7
8
O
...
O
I
O
O
P6.0
...
P6.4
P6.5
P6.6
P6.7
CS0
...
CS4
HOLD
HLDA
BREQ
Chip Select 0 Output
...
Chip Select 4 Output
External Master Hold Request Input
Hold Acknowledge Output
Bus Request Output
P8.0 -
P8.7
9 -
16
I/O
Port 8 is an 8-bit bidirectional I/O port. It is bit-wise
programmable for input or output via direction bits. For a pin
configured as input, the output driver is put into high-
impedance state. Port 8 outputs can be configured as push/
pull or open drain drivers. The input threshold of Port 8 is
selectable (TTL or special).
9
...
16
I/O
...
I/O
The following Port 8 pins also serve for alternate functions:
P8.0
...
CC16IO CAPCOM2: CC16 Cap.-In/Comp.Out
... ...
CC23IO CAPCOM2: CC23 Cap.-In/Comp.Out
P8.7
P7.0 -
P7.7
19 -
26
I/O
Port 7 is an 8-bit bidirectional I/O port. It is bit-wise
programmable for input or output via direction bits. For a pin
configured as input, the output driver is put into high-
impedance state. Port 7 outputs can be configured as push/
pull or open drain drivers. The input threshold of Port 7 is
selectable (TTL or special).
19
...
22
23
...
O
...
O
I/O
...
The following Port 7 pins also serve for alternate functions:
P7.0
...
POUT0
...
PWM Channel 0 Output
...
P7.3
P7.4
...
POUT3
PWM Channel 3 Output
CC28IO CAPCOM2: CC28 Cap.-In/Comp.Out
... ...
CC31IO CAPCOM2: CC31 Cap.-In/Comp.Out
26
I/O
P7.7
Semiconductor Group
5
