PROFET ITS 5215L
Thermal Characteristics
Parameter and Conditions
Symbol
Values
Unit
min
typ
max
Thermal resistance
junction - Case6)
each channel: RthjC
Rthja
one channel active:
all channels active:
K/W
--
--
--
--
--
--
45
40
5
--
--
--
junction – ambient6)
@ 6 cm2 cooling area
Electrical Characteristics
Parameter and Conditions, each of the four channels Symbol
Values
Unit
at Tj = -40...+150°C, V = 12 V unless otherwise specified
bb
min
typ
max
Load Switching Capabilities and Characteristics
On-state resistance (V to OUT); I = 2 A
L
bb
each channel,
--
--
mΩ
Tj = 25°C: RON
Tj = 150°C:
two parallel channels, Tj = 25°C:
70
90
140
180
--
35
45
--
see diagram, page 10
Nominal load current
one channel active: IL(NOM)
two parallel channels active:
3.7
7.4
4.7
9.5
A
6)
Device on PCB , T = 85°C, T ≤ 150°C
a
j
Output current while GND disconnected or pulled up7);
IL(GNDhigh)
--
--
2
mA
V
bb
= 32 V, V = 0,
IN
see diagram page 8
Turn-on time8)
Turn-off time
RL = 12 Ω
IN
IN
to 90% VOUT: ton
to 10% VOUT: toff
--
--
100
100
250
270
µs
Slew rate on8)
Slew rate off8)
10 to 30% VOUT, RL = 12 Ω: dV/dton
70 to 40% VOUT, RL = 12 Ω: -dV/dtoff
0.2
0.2
--
--
1.0 V/µs
1.1 V/µs
Device on 50mm*50mm*1.5mm epoxy PCB FR4 with 6cm2 (one layer, 70µm thick) copper area for V
connection. PCB is vertical without blown air. See page 13
not subject to production test, specified by design
6)
bb
7)
8)
See timing diagram on page 11.
Infineon Technologies AG
4
2006-Mar-27
