F3
ICE3AS02 / ICE3AS02G / ICE3BS02 / ICE3BS02G
Electrical Characteristics
Parameter
Symbol
Limit Values
Unit
Test Condition
min.
typ.
max.
Active Burst Mode Level for
Comparator C6b
VFBC6b
VVCCOVP
TjSD
3.25
3.40
3.55
18.1
150
-
V
After Active Burst
Mode is entered
Overvoltage Detection Limit
16.1
130
-
17.1
140
8.0
V
VFB > 5V
VSoftS < 4.0V
Thermal Shutdown1)
°C
µs
Spike Blanking
tSpike
1)
The parameter is not subject to production test - verified by design/characterization
Note: The trend of all the voltage levels in the Control Unit is the same regarding the deviation except VVCCOVP
and VVCCPD
4.3.6
Current Limiting
Parameter
Symbol
Limit Values
Unit
Test Condition
min.
typ.
max.
Peak Current Limitation
(incl. Propagation Delay Time of
external MOS)
Vcsth
0.97
1.02
1.07
V
dVsense / dt = 0.6V/µs
(see Figure 14)
Peak Current Limitation during
Active Burst Mode
VCS2
tLEB
0.232
-
0.257
220
0.282
V
Leading Edge Blanking
-
ns
µA
VSoftS = 4.4V
VCS =0V
CS Input Bias Current
ICSbias
-1.0
-0.2
0
Version 1.1
19
21 May 2004
