High Current PN Half Bridge
BTS 7960
Maximum Ratings
3
Maximum Ratings
-40 °C < Tj < 150 °C (unless otherwise specified)
Pos
Parameter
Symbol
Limits
Unit Test Condition
min max
Electrical Maximum Ratings
3.0.1 Supply voltage
VVS
VIN
-0.3 45
-0.3 5.3
V
V
3.0.2 Logic Input Voltage
VINH
3.0.3 HS/LS continuous drain ID(HS)
current
-40
401)
A
TC < 85°C
ID(LS)
switch active
3.0.4 HS pulsed drain current ID(HS)
3.0.5 LS pulsed drain current ID(LS)
-60
-60
601)
601)
A
A
V
V
TC < 85°C
tpulse = 10ms
3.0.6 Voltage at SR pin
VSR
-0.3 1.0
3.0.7 Voltage between VS and VVS -VIS -0.3 45
IS pin
3.0.8 Voltage at IS pin
VIS
-20
45
V
Thermal Maximum Ratings
3.0.9 Junction temperature
3.0.10 Storage temperature
Tj
Tstg
-40
-55
150 °C
150 °C
ESD Susceptibility
3.0.11 ESD susceptibility HBM VESD
kV
according to EIA/
JESD 22-A 114B
IN, INH, SR, IS
OUT, GND, VS
-2
-6
2
6
1)
Maximum reachable current may be smaller depending on current limitation level
Note: Maximum ratings are absolute ratings; exceeding any one of these values may
cause irreversible damage to the device. Exposure to maximum rating conditions
for extended periods of time may affect device reliability
Data Sheet
6
Rev. 1.1, 2004-12-07
