High Current PN Half Bridge
BTS 7960
Block Description and Characteristics
-40 °C < Tj < 150 °C, VS = 13.5 V, Rload = 2Ω (unless otherwise specified)
Pos. Parameter
Symbol
Limit Values
Unit Test Conditions
min. typ. max.
Low Side Switch Dynamic Characteristics
4.2.13 Rise-time of LS
tr(LS)
µs
0.5
–
2.8
1
2
7
1.5
–
11
R
R
R
SR = 0 Ω
SR = 5.1 kΩ
SR = 51 kΩ
4.2.14 Slew rate LS switch off ∆VOUT
/
V/µs
µs
tr(LS)
–
–
–
11
6
1.6
–
–
–
R
R
R
SR = 0 Ω
SR = 5.1 kΩ
SR = 51 kΩ
4.2.15 Switch off delay time tdr(LS)
LS
0.7
–
2.8
1.3
2.2
7
1.9
–
11.2
R
R
R
SR = 0 Ω
SR = 5.1 kΩ
SR = 51 kΩ
4.2.16 Fall-time of LS
tf(LS)
µs
0.5
–
2.8
1
2
7
1.5
–
11
R
R
R
SR = 0 Ω
SR = 5.1 kΩ
SR = 51 kΩ
4.2.17 Slew rate LS switch on -∆VOUT
/
V/µs
µs
tf(LS)
–
–
–
11
6
1.6
–
–
–
R
R
R
SR = 0 Ω
SR = 5.1 kΩ
SR = 51 kΩ
4.2.18 Switch on delay time tdf(LS)
LS
2.2
–
6.4
4
5.6
16
5.8
–
25.4
R
R
R
SR = 0 Ω
SR = 5.1 kΩ
SR = 51 kΩ
Data Sheet
12
Rev. 1.1, 2004-12-07
