AN985B/BX
Registers and Descriptors Description
Register 6
R6
Register 6
Offset
6H
Reset Value
0004H
ꢀꢁ
ꢀꢂ
ꢀꢃ
ꢀꢄ
ꢀꢀ
ꢀꢅ
5HV
UR
ꢆ
ꢇ
ꢈ
ꢉ
ꢁ
ꢂ
ꢃ
ꢄ
ꢀ
ꢅ
3') /313 13
URꢊꢋOK UR UR
35 /3$$
URꢊꢋOK UR
Field
Res
PDF
Bits
15:5
4
Type
ro
ro, lh
Description
Reserved
Parallel Detection Fault
Note:lh: Latch Hight
0B
1B
, No fault detected
, Local Device Parallel Detection Fault
LPNP
NP
3
2
1
ro
Link Partner Next Page Able
0B
1B
, Link Partner is not Next Page Able
, Link Partner is Next Page Able
ro
Next Page Able
0B
1B
, Local device is not Next Page Able
, Local device is Next Page Able
PR
ro, lh
Page Received
Note:lh: Latch Hight
0B
1B
, A New Page has not been received
, A New Page has been received
LPAA
0
ro
Link Partner Autonegotiation Able
0B
1B
, Link Partner is not Autonegotiation able
, Link Partner is Autonegotiation able
