IDT72T7285/72T7295/72T72105/72T72115 2.5V TeraSync
16,384 x 72, 32,768 x 72, 65,536 x 72, 131,072 x 72
72-BIT FIFO
COMMERCIAL AND INDUSTRIAL
TEMPERATURE RANGES
tCLKH
tCLKL
WCLK
tENH
tENS
WEN
HF
tHF
D/2 + 1 words in FIFO(1),
D/2 words in FIFO(1)
,
D/2 words in FIFO(1)
,
D-1
[
+ 2]
words in FIFO(2)
D-1
2
2
D-1
[
+ 1
]
words in FIFO(2)
[
+ 1
words in FIFO(2)
]
2
tHF
RCLK
tENS
REN
5994 drw32
NOTES:
1. In IDT Standard mode: D = maximum FIFO depth. D = 16,384 for the IDT72T7285, 32,768 for the IDT72T7295, 65,536 for the IDT72T72105 and 131,072 for the IDT72T72115.
2. In FWFT mode: D = maximum FIFO depth. D = 16,385 for the IDT72T7285, 32,769 for the IDT72T7295, 65,537 for the IDT72T72105 and 131,073 for the IDT72T72115.
3. RCS = LOW.
Figure 27. Half-Full Flag Timing (IDT Standard and FWFT Modes)
45
