FH33 Seriesꢀ0.4mm,0.5mm,1mm Pitch, 1.2mm above the board, Flexible Printed Circuit & Flexible Flat Cable ZIF Connectors
Precautions
Exercise care when handling connectors. Follow recommendations given below.
PC board flexing
SPC board connector mounting area
The connectors are straight within 0.1 mm max.
Make sure that the PC board connector mounting area flatness can accept the connector terminals without
causing any failure of the solder joints.
SHandling before mounting on PCB
Insertion of the FPC or operation of the actuator prior to mounting on the PCB is NOT RECOMMENDED.
SPC Board handling
Exercise caution when handling boards with the connectors installed. Do not apply any forces affecting
soldered joints.
Connector
PCB
Precautions When Inserting or Removing FPC
Pay attention to the following points when inserting FPC.
SActuator operation
Do not apply excessive force when opening the actuator prior to FPC insertion. When opening make sure
that the force is applied only to the actuator itself, avoiding touching of the contacts.
1
Damege to the contacts
Damage to the contacts
2 Axis of rotation
Axis of rotation
Assure free rotation of
the actuator
3 The actuator will rotate 120 degrees
maximum. Do not force it to rotate further.
12
