FH33 Seriesꢀ0.4mm,0.5mm,1mm Pitch, 1.2mm above the board, Flexible Printed Circuit & Flexible Flat Cable ZIF Connectors
ꢀPackaging Specifications
Embossed Carrier Tape Dimensions
(Tape width up to 24mm)
Embossed Carrier Tape Dimensions
(Tape width 32mm and over)
ꢀ
ꢀ
4
0.1 2 0.15
8
0.1
(1.7)
(0.3)
4
0.1 2 0.15
8
0.1
(1.7)
(0.3)
(3)
(3.8)
Flat surface for
placement with
automatic equipment
(1)
1.5+0.1
(3)
(3.8)
0
Unreeling direction
Flat surface for
placement with
automatic equipment
(1)
Unreeling direction
Reel Dimensions
ꢀ
(R:INSIDE)
(S:OUTSIDE)
End section
Mounting section
Lead section (400 mm min.)
Embossed carrier tape
Blank section
Blank section
(10 pockets min.)
Top cover tape
(10 pockets min.)
Note: 5,000 pieces per reel.
Embossed tape 32 mm or wider will have perforated feed holes on two sides.
8
