DF22 Series●7.92mm Contact Pitch High-Current Connectors for Internal Power Supplies (UL, C-UL and TÜV Listed)
■Retainer
For Standard height, standard lock (Type I)
For Long type, standard lock (Type III)
Long type, enhanced ergonomic lock (Type IV)
A
B
A
B
7.92
7.92
Cavity No.
Cavity No.
A5
4
3
2
1
A5
4
3
2
1
No. of contacts
indicator
No. of contacts
indicator
Unit : mm
Unit : mm
Part No.
HRS No.
No. of Contacts
A
B
Part No.
HRS No.
No. of Contacts
A
B
DF22-2RS/P-7.92 680-1209-7
DF22-3RS/P-7.92 680-1210-6
DF22-4RS/P-7.92 680-1211-9
DF22-5RS/P-7.92 680-1212-1
2
3
4
5
15.50 7.92 DF22B/C-2RS/P-7.92
23.42 15.84 DF22B/C-3RS/P-7.92
31.34 23.76 DF22B/C-4RS/P-7.92
39.26 31.68 DF22B/C-5RS/P-7.92
680-1200-2
680-1201-5
680-1202-8
680-1203-0
2
3
4
5
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
DF22-*S-7.92C For Standard height, standard lock
(Type I)
* indicates number of contacts.
DF22B-*S-7.92C For Long type, standard lock (Type III)
DF22C-*S-7.92C Long type, enhanced ergonomic lock (Type IV)
DF22-*EP-7.92C
Applicable Socket
Applicable Socket
DF22A-*EP-7.92C
* indicates number of contacts.
Note : Bag packaging (100 pcs/pack). Order by number of
packs.
Note 1 : Bag packaging (100 pcs/pack). Order by number of packs.
Note 2 : When connecting retainer into the plug housing, please
note the cavity numbers will line up numerieally, but the
retainer cavity numbers will be upside down compared to
the plug cavity numbers.
