DF22 Series●7.92mm Contact Pitch High-Current Connectors for Internal Power Supplies (UL, C-UL and TÜV Listed)
■Crimp Sockets (Height, Long Type)
Shown with terminated and contacts installed.
Shown with terminated and contacts installed.
A
B
1 Pos.
2 to 5 Pos.
P=7.92
8
Type 4
Type 4
Type 3
Height : Long type,
Height : Long type,
Height : Long type,
user-friendly operation
Enhanced
ergonomic lock
Standard lock
Contact No. 1
No. of contacts
indicator
Polarity
mark
(12.75)
(11.55)
(12.75)
Cavity No.
A
3
A
1
No. of contacts
indicator
Cavity No.
■ Type III
Height : Long type, Standard lock
■ Type IV
Height : Long type, Enhanced ergonomic lock
Standard Type (Guide Key : Inside, Color : White)
Standard Type (Guide Key : Inside, Color : White)
Unit : mm
Unit : mm
Part No.
No. of Contacts
A
B
Part No.
No. of Contacts
A
B
HRS No.
680-1097-5
680-1098-8
680-1099-0
680-1100-8
HRS No.
680-1101-0
680-1102-3
680-1103-6
680-1104-9
DF22B-2S-7.92C
DF22B-3S-7.92C
DF22B-4S-7.92C
DF22B-5S-7.92C
2
3
4
5
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
DF22C-1S-7.92C
DF22C-2S-7.92C
DF22C-3S-7.92C
DF22C-4S-7.92C
1
2
3
4
8.00 -----
15.50 7.92
23.42 15.84
31.34 23.76
Note 1 : Bag packaging (100 pcs/pack). Order by number of packs.
Note 2 : Every even number position has a different locking design.
R Type (Guide Key : Right Side, Color : Black)
Unit : mm
Part No.
No. of Contacts
A
B
HRS No.
DF22CR-3S-7.92C
680-1130-9
3
23.42 15.84
L Type (Guide Key : Left Side, Color : Red)
Unit : mm
Part No.
No. of Contacts
A
B
HRS No.
680-1133-7
680-1135-2
DF22CL-1S-7.92C
DF22CL-3S-7.92C
1
3
8.00 -----
23.42 15.84
Note 1 : Bag packaging (100 pcs/pack). Order by number of packs.
Note 2 : Every even number position has a different locking design.
4
