DF22 Series●7.92mm Contact Pitch High-Current Connectors for Internal Power Supplies (UL, C-UL and TÜV Listed)
■In-line Plug (Panel Lock Type)
Shown with terminated and contacts installed.
Shown with terminated and contacts installed.
3
A
B
3
1 Pos.
2, 3 Pos.
9.3
Contact No.1
No. of contacts
indicator
Cavity No.
No. of contacts
indicator
10.5
Cavity No.
A
1
3
A
Polarity
mark
3
2
1
16.3
C
Standard Type (Guide Key : Inside, Color : White)
Unit : mm
BPanel Cutout
Part No.
HRS No.
680-1048-0
680-1049-2
680-1050-1
No. of Contacts
A
B
C
Panel thickness
X
1 Pos.
DF22-1EP-7.92C
DF22-2EP-7.92C
DF22-3EP-7.92C
1
2
3
9.30 ----- 16.30
17.22 7.92 24.22
25.14 15.84 32.14
(15.8-X) +0.1
2.0
1.6
1.2
0.8
0.48
0.96
1.44
1.92
0
9.6+0.1
0
R Type (Guide Key : Right Side, Color : Black)
Unit : mm
Part No.
HRS No.
680-1059-6
680-1060-5
No. of Contacts
A
B
C
DF22R-2EP-7.92C
DF22R-3EP-7.92C
2
3
17.22 7.92 24.22
25.14 15.84 32.14
L Type (Guide Key : Left Side, Color : Red)
Unit : mm
2, 3 Pos.
(C-0.5-X) +0.1
0
Part No.
HRS No.
680-1063-3
680-1064-6
No. of Contacts
A
B
C
(A+0.4) +0.1
0
DF22L-1EP-7.92C
DF22L-2EP-7.92C
1
2
9.30 ----- 16.30
17.22 7.92 24.22
11 0.2
Note 1 : Bag packaging (100 pcs/pack). Order by number of packs.
Note 2 : Every even number position has a different locking design.
Note 1 : Please ensure when mating this connector
that the tapered portions of the panel are
facing outward towards the receptacle
connector’s mating interface.
7
