5.2 QFN-32 Package Dimensions
TOP
1
32
25
8
FT245RQ
9
16
YYXX-A
17
5.000
BOTTOM
0.500
24
23
22
21
25
26
27
28
29
30
31
32
0.150 Max
1
2
3
4
5
6
7
8
0.250
+/-0.050
20
19
18
17
0.200 Min
16
15
14
13
12
11
10
9
0.500
+/-0.050
3.200 +/-0.100
SIDE
0.800
+/-0.050
0.200
0.900
+/-0.100
0.050
Figure 9 - QFN-32 Package Dimensions
The FT245RQ is supplied in a RoHS compliant leadless QFN-32 package. The package is lead ( Pb ) free, and uses
a ‘green’ compound. The package is fully compliant with European Union directive 2002/95/EC.
This package has a compact 5.00mm x 5.00mm body. The solder pads are on a 0.50mm pitch. The above mechanical
drawing shows the QFN-32 package – all dimensions are in millimetres.
The centre pad on the base of the FT245RQ is not internally connected, and can be left unconnected, or connected to
ground (recommended).
The date code format is
YYXX
where XX = 2 digit week number, YY = 2 digit year number.
