FT2232C Dual USB UART / FIFO I.C.
7.0 Absolute Maximum Ratings
These are the absolute maximum ratings for the FT2232C device in accordance with the Absolute Maximum Rating System
(IEC 60134). Exceeding these may cause permanent damage to the device.
•
•
Storage Temperature …………………………………………………….............................. –65oC to + 150oC
Floor Life (Out of Bag) at Factory Ambient (30oC/60% Relative Humidity)........................192 Hours **Note 10
(Level 3 Compliant)
•
•
•
•
•
•
•
•
•
Ambient Temperature (Power Applied)……………………….............................................. 0oC to + 70oC
VCC Supply Voltage ……………………………………………….................................….... -0.5V to +6.00V
DC Input Voltage - Inputs ………………………………………………................................. -0.5V to VCC + 0.5V
DC Input Voltage - High Impedance Bidirectionals …………………….............................. -0.5V to VCC + 0.5V
DC Output Current – Outputs ……………………………………………............................... 24mA
DC Output Current – Low Impedance Bidirectionals …………………................................ 24mA
Power Dissipation (VCC = 5.25V) .……………………………………...............................… 500mW
Electrostatic Discharge Voltage (Human Body Model) (I < 1μA) …………......................… +/- 3000V
Latch Up Current (Vi = +/- 10V maximum, for 10 ms) ……………………........................... +/-200mA
**Note 10 – If devices are stored out of the packaging beyond this time limit the devices should be baked before use.
The devices should be ramped up to a temperature of 110oC and baked for 8 to 10 hours.
