Table 5. 2000 MHz Class A Test Circuit Component Designations and Values
Designators
Description
B1 - B5
C1, C9, C16
C2, C13
C3, C14
C4, C11
C5
Ferrite Beads, Round, Ferroxcube # 56-590-65-3B
100 μF, 50 V Electrolytic Capacitors, Mallory #SME50VB101M12X25L
51 pF Chip Capacitors, ATC #100B510JCA500x
10 pF Chip Capacitors, ATC #100B100JCA500X
12 pF Chip Capacitors, ATC #100B120JCA500X
0.8 - 8.0 pF Variable Capacitor, Johansen Gigatrim #27291SL
4.7 pF Chip Capacitor, ATC #100B4R7CCA500X
C6
C7, C15
C8
91 pF Chip Capacitors, ATC #100B910KP500X
1000 pF Chip Capacitor, ATC #100B102JCA50X
C10
0.1 μF Chip Capacitor, Kemet #CDR33BX104AKWS
C12, C17
L1
0.6 - 4.5 pF Variable Capacitors, Johansen Gigatrim #27271SL
4 Turns, #27 AWG, 0.087″ OD, 0.050″ ID, 0.069″ Long, 10 nH
5 Turns, #24 AWG, 0.083″ OD, 0.040″ ID, 0.128″ Long, 12.5 nH
9 Turns, #26 AWG, 0.080″ OD, 0.046″ ID, 0.170″ Long, 30.8 nH
1000 Ω Potentiometer, 1/2 W, 10 Turns, Bourns
L2
L3, L4
P1
Q1
Transistor, NPN, #MJD31, Case 369A-10
Q2
Transistor, PNP, #MJD32, Case 369A-10
R1
360 Ω, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B361JT
2 x 12 kΩ, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B122JT
1 Ω, Wirewound, 5 W, 3% Resistor, Dale # RE60G1R00
R2
R3
R4
4 x 6.8 kΩ, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B682JT
2 x 1500 Ω, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B152JT
270 Ω, Fixed Film Chip Resistor, 0.08″ x 0.13″, Garrett Instruments #RM73B2B271JT
12 Ω, Fixed Film Chip Resistors, 0.08″ x 0.13″, Garrett Instruments #RM73B2B120JT
R5
R6
R7 - R11
MRF284LR1 MRF284LSR1
